Moonwatt Sodium‑Ion BESS Boosts Solar Efficiency
Moonwatt’s modular sodium‑ion system delivers up to 94% solar‑to‑grid efficiency
Moonwatt’s new utility‑scale storage solution can convert sunlight into usable grid power with 94% efficiency in its DC‑coupled version and 93% in the AC‑coupled version, according to the company’s launch at The Smarter E trade show in Munich. The high efficiency comes from a direct DC link between the PV array and the battery, which reduces conversion losses compared with traditional containerised systems.
The system uses passively‑cooled sodium‑iron‑phosphate‑pyrophosphate (NFPP) cells, a chemistry that contains no lithium, cobalt, nickel or manganese, further reducing thermal‑management losses.
"The DC‑coupled interface to the PV system eliminates multiple conversion losses while achieving 94% efficiency from solar to battery to grid," the company said in its pv‑magazine release.
Distributed, container‑free design cuts balance‑of‑plant costs by up to 50%
Instead of a single, large container, Moonwatt’s Modular Enclosures (Moonpod units) are small, forklift‑movable boxes that can be spread across the solar field. The company claims this architecture reduces electrical balance‑of‑plant (BoP) costs by about 50% for the DC‑coupled version because it removes the need for extra transformers and high‑voltage cabling.
Each inverter block can host 1‑7 Moonpod units, scaling the battery’s AC power from 50 kW to 354 kW and its energy capacity from 202 kWh to 1,416 kWh. The modularity also means retrofits are simple – a unit can be placed on flat soil or gravel with no concrete foundation.
Passive cooling eliminates auxiliary power and cuts cycle losses by ~25%
Moonwatt’s NFPP cells are passively cooled, so no fans, pumps or HVAC equipment are required. The company states that this design loses up to 25% less energy per cycle than a comparable actively‑cooled lithium‑ion system, because no auxiliary power is drawn for thermal management. In practice the units draw zero auxiliary power, run silently and can be handled with a standard forklift (each weighs about 3.5 t).
Lifetime and scalability: up to 12,000 cycles and 1.4 MWh per inverter block
The battery is rated for 12,000 full‑depth‑of‑discharge cycles. At the maximum configuration of 1,416 kWh, the system can deliver many gigawatt‑hours of energy over its lifetime.
Technical specs per inverter block include 350 kVA apparent power, 350 kW bidirectional AC power, and operation at 800 V AC. The DC side accepts up to 600 kW of PV input with a voltage range of 500‑1,100 V and integrates 12 MPPTs (each with five strings).
Sodium‑ion vs. lithium‑ion: why the shift matters
Sodium‑ion batteries avoid critical minerals and are less sensitive to price spikes in lithium carbonate, which have been volatile in recent years. The NFPP chemistry also offers superior thermal stability, a key safety advantage for large, field‑deployed installations.
While lithium‑ion remains dominant, the global sodium‑ion market is projected to grow at a CAGR of 30% from 2025‑2034 (GMI Insights). Moonwatt’s modular, passive‑cooled design positions it to capture a share of the utility‑scale storage boom, especially where BoP cost and ease of installation are decisive.
What it means for Israel’s solar market
Israel’s residential solar tariffs sit at ≈ ₪0.48 /kWh and a typical 5‑kW rooftop system yields about 8,500 kWh / year in the central region (1700 kWh/kWp × 5 kWp). Adding Moonwatt’s storage to a utility‑scale plant of the same 600 kW capacity would generate roughly 1 GWh / year (600 kW × 1,700 kWh/kW). At the residential tariff, that translates to ≈ ₪480,000 / year of electricity value.
Because Moonwatt’s system can be placed directly on the PV field without extra transformers, developers could save up to 50% on balance‑of‑plant costs, making large‑scale solar‑plus‑storage projects more financially attractive in Israel’s competitive market. The high round‑trip efficiency (≈ 93‑94%) means more of the generated power can be sold or used during peak‑price periods, improving the economics of meeting the country’s 30% renewable electricity target for 2030.
A 600 kW plant equipped with the maximum 1,416 kWh of Moonwatt storage could store about 1.3 MWh of usable energy per day (93% of 1,416 kWh), providing a substantial amount of energy to help smooth solar variability without the heavy civil works required for traditional container BESS.
Outlook
Moonwatt will showcase the Moonpod at Intersolar Europe (June 25‑27, booth C2.190), and the company plans to scale the technology from kilowatts to gigawatts. As sodium‑ion chemistry gains market share and Europe pushes for critical‑material‑free storage, Israel’s solar developers are likely to watch closely – the combination of high efficiency, low BoP cost and easy installation could become a new standard for utility‑scale solar‑plus‑storage projects.
Sources & further reading
FAQ
What efficiency does Moonwatt’s sodium‑ion system achieve?
The DC‑coupled version reaches 94% solar‑to‑grid efficiency, while the AC‑coupled version hits about 93%.
How does the modular design affect installation?
Each Moonpod unit weighs 3.5 t and can be moved with a standard forklift, placed on flat soil without concrete foundations, eliminating the need for large containers and cranes.
What are the cost‑saving claims?
Moonwatt says the DC‑coupled architecture reduces electrical balance‑of‑plant costs by up to 50% compared with traditional containerised BESS.
How many cycles can the battery handle?
The system is rated for 12,000 full‑depth‑of‑discharge cycles, delivering roughly 17 GWh of energy over its lifetime at maximum capacity.
Why is sodium‑ion important for Israel?
Sodium‑ion avoids lithium, cobalt and nickel, sidestepping price volatility and critical‑material concerns while offering high efficiency that can boost the economics of meeting Israel’s 30% renewable target.
Can the system be retrofitted to existing solar farms?
Yes – the units connect on either the low‑voltage DC or AC side and need no additional medium‑voltage infrastructure, making retrofits straightforward.
